Ascometal® offers :
  • A comprehensive network based in France
  • Complementary production processes (continuous casting and ingot process)
  • Diversified sources of supply
  • Full controlled process and quality tracking
3 steel producing plants : Dunes, Fos-sur-Mer, Hagondange 2 finishing centers : Custines, Le Marais
Select a plant
Among our customers...

Custines

Cold finishing center of excellence for automotive component manufacturing.

Products

TYPEDIAMETER
Peeling, burnishing (Bars)*Ø 13 - 83mm,
up to tolerance band h9
Grinding (Bars)*Ø 10 - 80mm
up to tolerance band h8
(h7 for Ø < 30mm
on demand)
Finished/semi finished parts
• Sawing, chanfering (Bars)Ø 15 - 80mm,
length 2,500 - 10,000mm
• Sawing (Slug)*Ø 10 to 105mm, length
30mm to 2,000mm,
chamfering machine, center
hole, threading, marking
• Sawing, grinding (Slug)Ø 18 - 30mm
up to tolerance band h7,
length 350 - 1,000mm
* Feasible on tubes

Finishing equipments
  • Peeling: Kieserling lathes, Calow;
  • Cutting to length: Ohler saw;
  • Centerless grinding: Lidköping, R4B;
  • Sawing and machining: Wagner, Rattunde;
  • Controls: surface defects (eddy-current, MPI),
    anti-mix, dimensional controls.
Certifications
ISO 9001 • ISO/TS 16949 • ISO 14001 • OHSAS 18001

Address: ASCOMETAL® — site de Custines
252, rue du Pré-à-Varois BP 12
F-54670 Custines
Tel. : +33 3 83 92 60 00
Fax : +33 3 83 24 33 66

GPS position
N 48.785940
E 6.133242
